Building a Window Seat



How to Instructions on Building a Window Seat



By Mark J. Donovan



One of the most enjoyable features that I added to one of my homes was a window seat. I built the window seat underneath a large window that overlooked Lake Winnipesaukee.  Not only has it turned out to be a great place to enjoy the views and to sit back and read a book, it also now serves as an excellent place for storing away seasonal holiday items.



Building a Window Seat



Building a window seat is relatively simple to do. In my case the window was in a recessed dormer area that was about 18 inches deep, thus making it an ideal location for a window seat.



Tools Required for Building a Window Seat

  • Table Saw or Circular Saw

  • Miter Saw

  • Level

  • Pencil

  • Hammer

  • Screw Driver

  • Tape Measure

  • Safety Glasses

  • Paint Brush

Materials Required for Building a Window Seat

  • 2x4 Framing Studs

  • Nails

  • Beadboard panels

  • Single 4'x8' sheet of 3/4" Plywood

  • 20' of 1x3" Select Pine

  • Baseboard Trim

  • Corner Molding Trim

  • Paint / Polyurethane



To begin with I framed an 18 inch high wall, using 2”x4” studs that connected both sides of the dormer. I attached this framed window seat wall to the dormer side walls; such that it was flush with the inner wall, thus creating an 18 inch deep seating area.



Next I used a level to create a line on the inside seat area walls, so that they were level, and at the same heath, with the newly framed wall. I then screwed in 2x4 segments along the inside walls relative to these lines.

Building Window Seat

Photo by Mark Donovan





After building the basic frame for the window seat, I next framed in a center section due to the fact that the window seat was nearly 7 feet in length. Again, I made a simple framing wall 18” in length, and 18” in height and fastened it to the inside of the framed seating area.  I secured it to both the outer framed window seat wall and the back wall of the dormer. I also screwed it into the floor, as I had also done to the main window seat frame.



Next I dressed up the top of the frame with 1”x2” select pine material. I used finish nails to attach the finished pine boards to the 2x4 frame.



For the exterior walls of the window seat, I installed 2” wide tongue and grooved wainscoting boards mounted on the vertical.



To dress up the exterior of the window seat, I added some decorative moulding to both the top and bottom of the window seat, as well as on the corners. On the corners I actually used a wood corner bead. You could also use baseboard trim as well along the outside floor of the window seat.



For the top of the window seat, I used two 3/4” plywood panels cut to size, and then attached them to the back of the seat with hinges, after first painting them. I also drilled a single one inch hole in each panel near the front center of it, to enable the panel to be lifted.



Find a Qualified Finish Carpenter Contractor in Your Area

Get Free Quotes.  Easy, Quick and No Obligations!



For the home improvement or home remodeling project that is too big for you, check out our partner NeedContractor. They are a national resource for finding pre-screened, insured, and licensed home improvement and remodeling contractors in your local area.

Find Local, Pre-Screened Finish Carpenter Contractor



Get Matched in 48 hours with Finish Carpenter Contractors!



Finally, I applied two coats of polyurethane to the wainscoting and my window seat was complete, except for the cushions.



Fabricating the Window Seat Cushions



For the window seat cushions we had to by a large section of 4” thick foam and some cloth material. My wife then created one large cushion that lays on top of the window seat. We also added a couple of pillows and the window seat was ready for use.
